Model

EA0PF

EA0BF

EA0LF

Wavelength range

nm

1530~1565nm

Input power

dBm

-45~-25

-12~ +3

-25~ +3

Customizable

Max. output power

dBm

14

17/20/23/25/26

Adjustment range

dB

25

25

25

Noise index

dB

5

5

5.5

Working mode

-

ACC/APC/AGC

Parameter adjustment range

ACC ：0~100% ；APC ：10%~100% ；AGC ：0 ~25dB

-

Gain flatness

dB

≤1.5

APC/AGC ，10~25dB

Input/output isolation

dB

>35

Optical power monitoring

-

Input and output optical power monitoring

Fiber and connectors

-

SMF-28

PM1550

FC/APC connector

Polarization-dependent gain

dB

≤0.3

-

Polarization mode dispersion

ps

0.5

-

Polarization extinction ratio

dB

-

≥23

Control mode

Button/RS232 serial communication

RS232 Serial communication

Communication interface

DB9  Female

DB9  Female

Power supply

100~240V AC,   <30W

5V  DC,   <15W

Dimensions

260(W) ×280(D) × 120(H)mm

125(W) × 150(D) ×20(H)mm

Operating temperature range

-5~ +35°C

Operating humidity range

0~70%

Product Name

Working wavelength

Type

Saturated output power

Fiber Type

Connectors

Package Type

Optional configuration reserved

EA: Erbium-doped fiber amplifier

0：C wavelength

PF: Gain-flat small signal amplifier

PA-GF

A：11-15dbm

S：Single Mode

A:FC/APC

M：Modules

BF: Gain-flat power amplifier

BA-GF

B ：16-20dbm

P：Polarization Maintaining

B ：Benchtop

LF: Gain-flat line amplifier

LA-GF

C ：21-25dbm

D ：26-30dbm

EA0PFASAM

B80030304

C-band gain-flattened erbium-doped fiber amplifier, gain-flattened small signal amplifier PA-GF, saturated output power: 14dbm, single mode, FC/APC connector, module

EA0PFAPAM

B80030305

C-band gain-flattened erbium-doped fiber amplifier, gain-flattened small signal amplifier PA-GF, saturated output power: 14dbm, polarization-maintaining, FC/APC connector, module

EA0PFASAB

B80030306

C-band gain-flattened erbium-doped fiber amplifier, gain-flattened small signal amplifier PA-GF, saturated output power: 14dbm, single mode, FC/APC connector, benchtop

EA0PFAPAB

B80030307

C-band gain-flattened erbium-doped fiber amplifier, gain-flattened small signal amplifier PA-GF, saturated output power: 14dbm, polarization-maintaining, FC/APC connector, benchtop

EA0BFBSAM

B80030308

C-band gain-flattened erbium-doped fiber amplifier, gain-flattened power amplifier BA-GF, saturated output power: 17/20dbm, single mode, FC/APC connector, module

EA0BFCSAM

B80030309

C-band gain-flattened erbium-doped fiber amplifier, gain-flattened power amplifier BA-GF, saturated output power: 23/25dbm, single mode, FC/APC connector, module

EA0BFDSAM

B80030310

C-band gain-flattened erbium-doped fiber amplifier, gain-flattened power amplifier BA-GF, saturated output power: 26dbm, single mode, FC/APC connector, module

EA0BFBPAM

B80030311

C-band gain-flattened erbium-doped fiber amplifier, gain-flattened power amplifier BA-GF, saturated output power: 17/20dbm, polarization-maintaining, FC/APC connector, module

EA0BFCPAM

B80030312

C-band gain-flattened erbium-doped fiber amplifier, gain-flattened power amplifier BA-GF, saturated output power: 23/25dbm, polarization-maintaining, FC/APC connector, module

EA0BFDPAM

B80030313

C-band gain-flattened erbium-doped fiber amplifier, gain-flattened power amplifier BA-GF, saturated output power: 26dbm, polarization-maintaining, FC/APC connector, module

EA0BFBSAB

B80030314

C-band gain-flattened erbium-doped fiber amplifier, gain-flattened power amplifier BA-GF, saturated output power: 17/20dbm, single mode, FC/APC connector, benchtop

EA0BFCSAB

B80030315

C-band gain-flattened erbium-doped fiber amplifier, gain-flattened power amplifier BA-GF, saturated output power: 23/25dbm, single mode, FC/APC connector, benchtop

EA0BFDSAB

B80030316

C-band gain-flattened erbium-doped fiber amplifier, gain-flattened power amplifier BA-GF, saturated output power: 26dbm, single mode, FC/APC connector, benchtop

EA0BFBPAB

B80030317

C-band gain-flattened erbium-doped fiber amplifier, gain-flattened power amplifier BA-GF, saturated output power: 17/20dbm, polarization-maintaining, FC/APC connector, desktop

EA0BFCPAB

B80030318

C-band gain-flattened erbium-doped fiber amplifier, gain-flattened power amplifier BA-GF, saturated output power: 23/25dbm, polarization-maintaining, FC/APC connector, benchtop

EA0BFDPAB

B80030319

C-band gain-flattened erbium-doped fiber amplifier, gain-flattened power amplifier BA-GF, saturated output power: 26dbm, polarization-maintaining, FC/APC connector,benchtop

EA0LFBSAM

B80030320

C-band gain-flattened erbium-doped fiber amplifier, gain-flattened line amplifier LA-GF, saturated output power: 17/20dbm, single mode, FC/APC connector, module

EA0LFCSAM

B80030321

C-band gain-flattened erbium-doped fiber amplifier, gain-flattened line amplifier LA-GF, saturated output power: 23/25dbm, single mode, FC/APC connector, module

EA0LFDSAM

B80030322

C-band gain-flattened erbium-doped fiber amplifier, gain-flattened line amplifier LA-GF, saturated output power: 26dbm, single mode, FC/APC connector, module

EA0LFBPAM

B80030323

C-band gain-flattened erbium-doped fiber amplifier, gain-flattened line amplifier LA-GF, saturated output power: 17/20dbm, polarization-maintaining, FC/APC connector, module

EA0LFCPAM

B80030324

C-band gain-flattened erbium-doped fiber amplifier, gain-flattened line amplifier LA-GF, saturated output power: 23/25dbm, polarization-maintaining, FC/APC connector, module

EA0LFDPAM

B80030325

C-band gain-flattened erbium-doped fiber amplifier, gain-flattened line amplifier LA-GF, saturated output power: 26dbm, polarization-maintaining, FC/APC connector, module

EA0LFBSAB

B80030326

C-band gain-flattened erbium-doped fiber amplifier, gain-flattened line amplifier LA-GF, saturated output power: 17/20dbm, single mode, FC/APC connector, benchtop

EA0LFCSAB

B80030327

C-band gain-flattened erbium-doped fiber amplifier, gain-flattened line amplifier LA-GF, saturated output power: 23/25dbm, single mode, FC/APC connector, benchtop

EA0LFDSAB

B80030328

C-band gain-flattened erbium-doped fiber amplifier, gain-flattened line amplifier LA-GF, saturated output power: 26dbm, single mode, FC/APC connector, benchtop

EA0LFBPAB

B80030329

C-band gain-flattened erbium-doped fiber amplifier, gain-flattened line amplifier LA-GF, saturated output power: 17/20dbm, polarization-maintaining, FC/APC connector, benchtop

EA0LFCPAB

B80030330

C-band gain-flattened erbium-doped fiber amplifier, gain-flattened line amplifier LA-GF, saturated output power: 23/25dbm, polarization-maintaining, FC/APC connector, benchtop

EA0LFDPAB

B80030331

C-band gain-flattened erbium-doped fiber amplifier, gain-flattened line amplifier LA-GF, saturated output power: 26dbm, polarization-maintaining, FC/APC connector, benchtop
