Filter

Long wave pass filter

Standard long wave pass filters are in stock, depending on previous sales performance (wavelength range UV, VIS, NIR, and IR). If you cannot find a suitable filter for your application in the list below, please contact Xiaoxiao Photon's sales team for further assistance. Please note that our 'inventory' filters are not boxed, bagged, labeled, or placed on shelves for immediate use. Our inventory includes thousands of types of filters and components. Sometimes, components that are only in stock still need to be glued together to make multi-component filters. Filters and components must be removed from inventory, cleaned, remeasured, and inspected, packaged, and transported by QC.

Product PN#	product name	Wavelength	Substrate	Thickness	Cuton 5% Deviation	Transmittance
LP-0880 nm	880nm long wave pass filter	880nm	Glass	0.5mm	±10nm	> 70%	Add Inquiry
LP-1300 nm	1300nm long wave pass filter	1300nm	Silicon	1mm	±30nm	> 70%	Add Inquiry
LP-1500 nm	1500nm long wave pass filter	1500nm	Silicon	1mm	±50nm	> 75%	Add Inquiry
LP-2000 nm	2000nm long wave pass filter	2000nm	Germanium	1mm	±50nm	> 70%	Add Inquiry
LP-4700 nm	4700nm long wave pass filter	4700nm	Sapphire	0.47mm	±100nm	> 70%	Add Inquiry

Full band narrowband filter

Standard narrowband pass filters are available in stock, depending on previous sales performance (wavelength range UV, VIS, NIR, and IR). If you cannot find a suitable filter for your application in the list below, please contact Xiaoxiao Photon's sales team for further assistance. Please note that our 'inventory' filters are not boxed, bagged, labeled, or placed on shelves for immediate use. Our inventory includes thousands of types of filters and components. Sometimes, components that are only in stock still need to be glued together to make multi-component filters. Filters and components must be removed from inventory, cleaned, remeasured, and inspected, packaged, and transported by QC.

Product PN#	product name	Center wavelength	Substrate	Thickness	Center wavelength deviation	Half width high bandwidth deviation	Transmittance
NB-0760-025 nm	760nm Narrowband Pass Filter	760nm	N-bk7	1mm	±7nm	±5nm	>80%	Add Inquiry
NB-1300-008 nm	1300nm Narrowband Pass Filter	1300nm	Cemented	1mm	±5nm	±3nm	>55%	Add Inquiry
NB-1548-120 nm	1548nm Narrowband Pass Filter	1548nm	Glass	0.5mm	±20nm	±20nm	>65%	Add Inquiry
NB-1790-010 nm	1790nm Narrowband Pass Filter	1790nm	Cemented	0.85mm	±5nm	±2nm	>60%	Add Inquiry
NB-2048-030 nm	2048nm narrowband pass filter	2048nm	Cemented	1mm	±10nm	±5nm	>70%	Add Inquiry

Full band bandpass filter

Standard bandpass filters are in stock, depending on previous sales performance (wavelength range UV, VIS, NIR, and IR). If you cannot find a suitable filter for your application in the list below, please contact Xiaoxiao Photon's sales team for further assistance. Please note that our 'inventory' filters are not boxed, bagged, labeled, or placed on shelves for immediate use. Our inventory includes thousands of types of filters and components. Sometimes, components that are only in stock still need to be glued together to make multi-component filters. Filters and components must be removed from inventory, cleaned, remeasured, and inspected, packaged, and transported by QC.

Product PN#	product name	Center wavelength	Substrate	Thickness	Center wavelength deviation	Half width high bandwidth deviation	Transmittance
BP-0750-040 nm	750nm bandpass filter	750nm	Colour glass	1.8mm	±7nm	±7nm	>70%	Add Inquiry
BP-1535-080 nm	1535nm bandpass filter	1535nm	N-bk7	1mm	±6nm	±6nm	>75%	Add Inquiry
BP-1695-095 nm	1695nm bandpass filter	1695nm	Cemented	1mm	±20nm	±20nm	>70%	Add Inquiry
BP-2010-113 nm	2010nm bandpass filter	2010nm	Cemented	0.8mm	±15nm	±15nm	>60%	Add Inquiry
BP-3330-145 nm	3330nm bandpass filter	3330nm	Sapphire	0.5mm	±30nm	±20nm	>70%	Add Inquiry

Broadband pass filter

Standard broadband filters are in stock, depending on previous sales performance (wavelength range UV, VIS, NIR, and IR). If you cannot find a suitable filter for your application in the list below, please contact Xiaoxiao Photon's sales team for further assistance. Please note that our 'inventory' filters are not boxed, bagged, labeled, or placed on shelves for immediate use. Our inventory includes thousands of types of filters and components. Sometimes, components that are only in stock still need to be glued together to make multi-component filters. Filters and components must be removed from inventory, cleaned, remeasured, and inspected, packaged, and transported by QC.

Product PN#	product name	Band	Substrate	Thickness	HP1 50% Deviation	HP2 50% Deviation	Transmittance
BBP-1260-1500 nm	1260-1500nm broadband pass filter	1260-1500nm	Glass	0.55mm	±50nm	±50nm	>70%	Add Inquiry
BBP-1615-2280 nm	1615-2280nm broadband pass filter	1615-2280nm	Silicon	0.5mm	±50nm	±50nm	>70%	Add Inquiry
BBP-2960-3260 nm	2960-3260nm broadband pass filter	2960-3260nm	Quartz	1mm	±75nm	±75nm	>70%	Add Inquiry
BBP-3950-6250 nm	3950-6250nm broadband pass filter	3950-6250nm	Silicon	0.5mm	±100nm	±120nm	>70%	Add Inquiry
BBP-8075-9400 nm	8075-9400nm broadband pass filter	8075-9400nm	Germanium	1mm	±150nm	±150nm	>70%	Add Inquiry

Neutral density filter

A neutral density filter is a special optical component that can uniformly attenuate all wavelengths of light in the visible to near-infrared range. Standard neutral density filters are in stock and subject to previous sales. If you cannot find a suitable filter for your application in the list below, please contact Xiaoxiao Photon's sales team for further assistance.

Product PN#	product name	Band	Substrate	Thickness	Transmittance	Transmittance Deviation
ND-UV-VIS-OD-0.6-Ø25.4x0.5 mm	200-2500nm neutral density filter	200-2500nm	Quartz	0.5mm	25%	±5%	Add Inquiry
ND-IR-OD-2.0-Ø50.8x1.0 mm	2000-16000nm neutral density filter	2000-16000nm	Germanium	1mm	1%	±0.25%	Add Inquiry
ND-IR-OD-0.1-Ø25.4x1.0 mm	2000-5000nm neutral density filter	2000-5000nm	Sapphire	1mm	80%	±5%	Add Inquiry

Gas analysis infrared filter

Xiaoxiao Photon's standard infrared filter is used to measure various gases such as CO, CO2, and SO2.

Product PN#	product name	Center wavelength	Half width high bandwidth	Transmittance	Gas	Substrate
BP-3050-100 nm	3050nm infrared filter	3050nm	100nm	70%	C₂H₂	Sapphire	Add Inquiry
NB-4265-120 nm Si	4265nm infrared filter	4265nm	120nm	70%	CO₂	Silicon	Add Inquiry
NB-4525-083 nm Si	4525nm infrared filter	4525nm	83nm	70%	N₂O	Silicon	Add Inquiry
NB-4720-090 nm	4720nm infrared filter	4720nm	90nm	70%	CO	Sapphire	Add Inquiry

Short wave pass filter

Standard short wave pass filters are in stock, depending on previous sales performance (wavelength range UV, VIS, NIR, and IR). If you cannot find a suitable filter for your application in the list below, please contact Xiaoxiao Photon's sales team for further assistance. Please note that our 'inventory' filters are not boxed, bagged, labeled, or placed on shelves for immediate use. Our inventory includes thousands of types of filters and components. Sometimes, components that are only in stock still need to be glued together to make multi-component filters. Filters and components must be removed from inventory, cleaned, remeasured, and inspected, packaged, and transported by QC.

Product PN#	product name	Wavelength	Substrate	Thickness	Cutoff 5% Deviation	Transmittance
SP-0505 nm	505nm short wave pass filter	505nm	N-bk7	1mm	±30nm	> 80%	Add Inquiry
SP-1000 nm	1000nm short wave pass filter	1000nm	Glass	0.5mm	±50nm	> 70%	Add Inquiry
SP-1300 nm	1300nm short wave pass filter	1300nm	Glass	0.5mm	±50nm	> 60%	Add Inquiry
SP-1550 nm	1550nm short wave pass filter	1550nm	N-bk7	1mm	±30nm	> 70%	Add Inquiry
SP-2050 nm	2050nm short wave pass filter	2050nm	Glass	0.5mm	±50nm	> 70%	Add Inquiry
