Fiber laser

1550nm high-power single-mode fiber laser

With optimized optical properties, 1550nm single-mode DFB has become an ideal choice for high demand sensing system applications. Innovative chip design has suppressed high-order longitudinal and transverse modes while maintaining linear polarization stability. Laser has high output power (Max50W output), narrow linewidth, and good consistency, which are currently highly favored by domestic scientific research customers. At present, our existing inventory covers wavelengths ranging from 1000-2400nm. We can provide customized chip screening services for customers in certain specific application areas.

Product PN#	product name	Center wavelength	Output power
LP-1550-B-3-1-SA	1550nm high-power single-mode fiber laser 3W	1550nm	3W	Add Inquiry
LP-1550-B-10-1-PA	1550nm high-power polarization maintaining fiber laser 10W	1550nm	10W	Add Inquiry
LP-1550-B-2-1-PA	1550nm high-power polarization maintaining fiber laser 2W	1550nm	2W	Add Inquiry
LP-1550-B-10-1-SA	1550nm high-power single-mode fiber laser 10W	1550nm	10W	Add Inquiry
LP-1550-B-2-1-SA	1550nm high-power single-mode fiber laser 2W	1550nm	2W	Add Inquiry

1064nm high-power fiber laser 2W/10W

With optimized optical properties, 1064nm single-mode DFB is an ideal choice for high demand sensing system applications. Innovative chip design has suppressed high-order longitudinal and transverse modes while maintaining linear polarization stability. Laser has high output power, narrow linewidth, and good consistency, which are currently highly favored by domestic scientific research customers. At present, our existing inventory covers wavelengths ranging from 1000-2400nm. We can provide customized chip screening services for customers in certain specific application areas.

Product PN#	product name	Center wavelength	Output power
LP-1064-B-10-1-PA	1064nm high-power polarization maintaining fiber laser 10W	1064nm	10W	Add Inquiry
LP-1064-B-2-1-PA	1064nm high-power polarization maintaining fiber laser 2W	1064nm	2W	Add Inquiry
LP-1064-B-10-1-SA	1064nm high-power single-mode fiber laser 10W	1064nm	10W	Add Inquiry
LP-1064-B-2-1-SA	1064nm high-power single-mode fiber laser 2W	1064nm	2W	Add Inquiry

LuMIR 3200 mid infrared continuous power fiber laser 3.1-3.3um 5W

The 3200 series provides an average power of 5W at 3.25 microns, meeting the needs of most organic material processing, sensing, and defense applications. Its design can be customized to any wavelength between 3.1 and 3.3 microns to suit your specific application.

Product PN#	product name	Working wavelength	Output power	Line width	Other parameters
LumIR-3200	LuMIR 3200 mid infrared continuous power fiber laser 3.25um 5W	3.25um（标准）	高达 5W	<1nm		Add Inquiry

OYAT 80-515 Industrial High Power Picosecond Quasi Continuous Fiber Laser 515nm (80W 30ps 30MHz)

OYAT is a quasi continuous fiber laser that can provide high power and high-frequency picosecond pulses. Its innovative fiber design achieves high power, high pulse repetition rate, picosecond pulses, all of which are in a single-mode beam of visible light at 515 nm. The combination of fiber optic technology and a simple and efficient laser head frame makes OYAT a durable and cost-effective visible QCW laser suitable for demanding industrial applications. The BLOOM laser adopts field validated technology, qualified components, and good practical manufacturing, with good working stability.

Product PN#	product name	Center wavelength	Output power	Pulse duration	Other parameters
OYAT-80-515	Industrial high-power picosecond quasi continuous fiber laser 515nm (80W 30ps 30MHz)	515 nm	80 W @ 30 MHz	30 ps		Add Inquiry

LuMIR 2800 mid infrared continuous power fiber laser 2.8um 10W

The 2800 series adopts a sturdy and durable all fiber design, which can provide an average power of 10 W at the peak of water molecule absorption. Its standard emission wavelength is 2825 nm or 2910 nm, and can also be customized to any wavelength between 2790 nm and 2940 nm according to your specific needs. The 2800 series can be highly absorbed by water rich biological tissues, making it ideal for medical and cosmetic applications. The 2800 series features diffraction limited beam quality, compact design, and flexible transmission methods to deliver beams to where you need them.

Product PN#	product name	Center wavelength	Output power	Line width	Other parameters
LumIR-2800-10	LuMIR 2800 mid infrared continuous power fiber laser 2.8um 10W	2.825µm（标称）	10W	＜1nm		Add Inquiry

1-3 μ m fiber laser source

It has the characteristics of high efficiency, high-quality beam quality, compact design, high stability and reliability, and is widely used in industrial processing, material processing, medical, scientific research and communication fields.

Product PN#	product name	Center wavelength	Average power	Bandwidth	ASE suppression
OEFLS-100-1050-10	1050nm fiber laser source (high power)	1050nm	10W	<0.05nm	>50dB	Add Inquiry
OEFLS-100-1550-5	1550nm fiber laser source (high power)	1550nm	5W	<0.05nm	>50dB	Add Inquiry
OEFLS-100-1650-0.9	1650nm fiber laser source (high power)	1650nm	0.9W	<0.5nm	>40dB	Add Inquiry
OEFLS-100-2000-20	2000nm fiber laser source (high power)	2000nm	20W	<1nm	>50dB	Add Inquiry

1.2-2.3 μ m Raman fiber laser source

Xiaoxiao Photon's customized Raman fiber laser source provides up to 20W output power in a wide wavelength range of 1090-2400nm, making it suitable for many applications including but not limited to EDFA pumping, Raman amplification, optical component testing, and research and development.

Product PN#	product name	Center wavelength	Average power	3dB bandwidth	ASE suppression
OEFLS-RM-100-1240-10	1240nm Raman fiber laser source	1240nm	10W	3nm	>30dB	Add Inquiry
OEFLS-RM-100-1320-0.6	1320nm Raman fiber laser source	1320nm	0.6W	3nm	>30dB	Add Inquiry
OEFLS-RM-100-1480-5	1480nm Raman fiber laser source	1480nm	5W	3nm	>30dB	Add Inquiry
OEFLS-RM-100-1688-0.6	1688nm Raman fiber laser source	1688nm	0.6W	0.3nm	>30dB	Add Inquiry
