Si balanced photodetector
Silicon Si Optoelectronic Balance Detector BPD-SI Series 400~1100nm
The high-speed low-noise optoelectronic balance detection module integrates two matched ultra-low noise analog PIN detectors, a low-noise broadband transimpedance amplifier, and an ultra-low noise power supply. It has the characteristics of high gain, high sensitivity, high bandwidth, low noise, and high common mode rejection ratio, which can effectively reduce the common mode noise of the signal and improve the signal-to-noise ratio of the system.
Product PN# product name Working wavelength bandwidth responsivity Other parameters
BPD-Si-1G-B 400-1100nm silicon Si photoelectric balanced detector 1GHz 400-1100nm 1GHz 0.55A/W @850nm Add Inquiry
BPD-Si-500M-B 400-1100nm silicon Si photoelectric balanced detector 500MHz 400-1100nm 500MHz 0.55A/W @850nm Add Inquiry
BPD-Si-350M-B 400-1100nm silicon Si photoelectric balanced detector 350MHz 400-1100nm 350MHz 0.55A/W @850nm Add Inquiry
BPD-Si-200M-B 400-1100nm silicon Si photoelectric balance detector 200MHz 400-1100nm 200MHz 0.55A/W @850nm Add Inquiry
BPD-Si-100M-B 400-1100nm silicon Si photoelectric balanced detector 100MHz 400-1100nm 100MHz 0.55A/W @850nm Add Inquiry
Silicon Si Balance Detector MBD-B Series 400-1100nm
The Si balance detection module integrates two matched low-noise analog PIN detectors, a low-noise broadband transimpedance amplifier, and an ultra-low noise power supply. It has the characteristics of high gain, high sensitivity, high bandwidth, low noise, and high common mode rejection ratio, which can effectively reduce the common mode noise of the signal and improve the signal-to-noise ratio of the system.
Product PN# product name Wavelength Bandwidth Detector Responsiveness Other parameters
MBD-100M-B-FC/APC Si balanced detector 100MHz 400-1100nm FC/APC 400-1100nm 100MHz 0.55A/W@850nm Add Inquiry
MBD-200M-B-FC/APC Si balanced detector 200MHz 400-1100nm FC/APC 400-1100nm 200MHz 0.55A/W@850nm Add Inquiry
MBD-300M-B-FC/APC Si balanced detector 300MHz 400-1100nm FC/APC 400-1100nm 300MHz 0.55A/W@850nm Add Inquiry
MBD-400M-B-FC/APC Si balanced detector 400MHz 400-1100nm FC/APC 400-1100nm 400MHz 0.55A/W@850nm Add Inquiry
MBD-500M-B-FC/APC Si balanced detector 500MHz 400-1100nm FC/APC 400-1100nm 500MHz 0.55A/W@850nm Add Inquiry
MBD-1G-B-FC/APC Si balanced detector 1GHz 400-1100nm FC/APC 400-1100nm 1GHz 0.55A/W@850nm Add Inquiry
Silicon Si Optoelectronic Balance Detector BPD-SI Series 400~1100nm
The high-speed low-noise optoelectronic balance detection module integrates two matched ultra-low noise analog PIN detectors, a low-noise broadband transimpedance amplifier, and an ultra-low noise power supply. It has the characteristics of high gain, high sensitivity, high bandwidth, low noise, and high common mode rejection ratio, which can effectively reduce the common mode noise of the signal and improve the signal-to-noise ratio of the system.
Product PN# product name Wavelength Bandwidth Detector Responsiveness Output Coupling Method Other parameters
BPD-Si-1G-B Silicon Si Optoelectronic Balance Detector 400-1100nm 1GHz 400~1100 1G 0.55@850nm AC Add Inquiry
