Fiber Optic WDM

Dual wavelength combiner/splitter (WDM)

Based on thin filter technology, it provides the ability to combine two laser wavelengths that are far apart into a single fiber output. The merged wavelengths can be specified by the customer and are at least 200nm apart. This device has the potential to combine wavelengths ranging from 400 to 2000 nanometers across the entire range.

Product PN#	product name	Working wavelength	Structure	Other parameters
OEWBC-2x1-975/2000-T1-C2-1	Dual wavelength combiner/splitter	975/2000nm	2×1		Add Inquiry

Multi wavelength combiner/splitter (WDM)

Based on volume grating technology, several close laser wavelengths can be combined into a single fiber output. The wavelength for merging can be specified by the customer, and the distance between them can be close to 10nm. The number of merged wavelength channels can also be specified. This device has the potential to combine wavelengths ranging from 400 to 2000 nanometers across the entire range.

Product PN#	product name	Number of channels	Operating wavelength range	Other parameters
OEMWC-100-3-1030-T1-C2-1	Multi wavelength combiner/splitter	3	1030+1040+1050nm		Add Inquiry

DWDM filter (FBG only)

Xiaoxiao Photon's DWDM FBG fiber Bragg grating filter has attracted more attention due to its flat top and steep spectral slope. Using our unique toe mask technology and FBG writing technology, we have fabricated DWDM fiber grating filters with an isolation greater than 40 dB and a reflection bandwidth of -25 dB. The reflection bandwidths are less than 1 nm (100 GHz), 0.5 nm (50 GHz), 0.25 nm (25 GHz), 0.13 nm (12.5 GHz), and 0.06 nm (6.25 GHz), respectively.

Product PN#	product name	Center wavelength	Channel spacing	Channel isolation
OEWDM-012-1520-P1-T2-C3-1.5	1520nm DWDM filter (FBG only)	1520nm	12.5GHz	30dB	Add Inquiry
OEWDM-025-1550-P1-T2-C3-1.5	1550nm DWDM filter (FBG only)	1550nm	25GHz	30dB	Add Inquiry
OEWDM-050-1565.5-P2-T2-C3-1.5	1565.5nm DWDM filter (FBG only)	1565.5nm	50GHz	30dB	Add Inquiry
OEWDM-100-1600-P2-T2-C2-1.0	1600nm DWDM filter (FBG only)	1600nm	100GHz	30dB	Add Inquiry
OEWDM-200-1675-P2-T2-C2-1.0	1675nm DWDM filter (FBG only)	1675nm	200GHz	30dB	Add Inquiry

DWDM add/drop module (FBG with simulator)

Xiaoxiao Photon's single channel DWDM FBG add/drop module is based on advanced fiber Bragg grating (FBG) filtering technology and has three ports for multiplexing or demultiplexing. One of the main advantages of this device is the flexibility of channel wavelength selection, which can be any wavelength specified within the S, C, and L band ranges. This device can be used to add or remove any single channel wavelength from an array of multiple wavelengths. The channel spacing can be selected from 6.25Ghz, 12.5Ghz, 25Ghz, 50Ghz, 100Ghz, and 200Ghz.

Product PN#	product name	Center wavelength	Channel spacing	Reflection bandwidth
OEWAD-012-1520-P2-T1-C2-1.0	1520nm DWDM add/drop module (FBG with simulator)	1520nm	12.5GHz	< 0.13nm	Add Inquiry
OEWAD-025-1550-P2-T1-C2-1.0	1550nm DWDM add/drop module (FBG with simulator)	1550nm	25GHz	< 0.25nm	Add Inquiry
OEWAD-050-1565-P2-T1-C2-1.0	1565nm DWDM add/drop module (FBG with simulator)	1565nm	50GHz	< 0.5nm	Add Inquiry
OEWAD-100-1600-P2-T1-C2-1.0	1600nm DWDM add/drop module (FBG with simulator)	1600nm	100GHz	< 1.0nm	Add Inquiry
OEWAD-200-1675-P2-T1-C2-1.0	1675nm DWDM add/drop module (FBG with simulator)	1675nm	200GHz	< 2.0nm	Add Inquiry

DWDM multiplexer (multi-channel, splitter multiplexer)

Xiaoxiao Photon's multi-channel DWDM FBG wavelength division multiplexer is based on our advanced fiber Bragg grating (FBG) filtering technology and has multiple ports for multiplexing or demultiplexing. The maximum number of available channels is 8, and the configuration on the port is 1x9. One of the advantages of this device is the flexibility to choose the number of channels and wavelengths, which can be any one within the ITU grid or customer specified S, C, and L band ranges. This device can simultaneously achieve multiplexing or demultiplexing of 2 to 8 channels. The channel spacing can be selected within the range of 6.25 GHz, 12.5 GHz, 25 GHz, 50 GHz, 100 GHz, and 200 GHz.

Product PN#	product name	Center wavelength	Number of channels	Channel spacing	Reflection bandwidth
OEWDM-012-5-1520-P2-T1-C2-1	1520nm DWDM multiplexer (multi-channel, splitter multiplexer)	1520nm	5	12.5GHz	<0.13nm	Add Inquiry
OEWDM-025-5-1550-P2-T1-C2-1	1550nm DWDM multiplexer (multi-channel, splitter multiplexer)	1550nm	5	25GHz	<0.25nm	Add Inquiry
OEWDM-050-5-1565-P2-T1-C2-1	1565nm DWDM multiplexer (multi-channel, splitter multiplexer)	1565nm	5	50GHz	<0.5nm	Add Inquiry
OEWDM-100-5-1600-P2-T1-C2-1	1600nm DWDM multiplexer (multi-channel, splitter multiplexer)	1600nm	5	100GHz	<1.0nm	Add Inquiry
OEWDM-200-5-1675-P2-T1-C2-1	1675nm DWDM multiplexer (multi-channel, splitter multiplexer)	1675nm	5	200GHz	<2.0nm	Add Inquiry

Fiber optic wavelength division multiplexer (visible light)

Xiaoxiao Photon's wavelength division multiplexer (WDM) is used to mix or split two beams of light with different wavelengths. We offer a variety of wavelength division multiplexers, whose wavelength combinations span the visible, near-infrared, and infrared spectra. Our visible light wavelength division multiplexers are also known as "wavelength combiners" because they are commonly used in microscopy applications to generate multi-color composite images.

Product PN#	product name	Working wavelength	Working bandwidth	Isolation	Return loss
WD5335-0	532 (G)/635 (R) nm single-mode tapered wavelength division multiplexer (FC/APC)	532(G)/635(R)nm	±5nm	≥20.00dB	≥50.00dB	Add Inquiry
WD5335-1	532 (G)/635 (R) nm single-mode tapered wavelength division multiplexer (FC/PC)	532(G)/635(R)nm	±5nm	≥20.00dB	≥50.00dB	Add Inquiry
WD5335-4	532 (G)/635 (R) nm single-mode tapered wavelength division multiplexer (bare fiber)	532(G)/635(R)nm	±5nm	≥20.00dB	≥50.00dB	Add Inquiry
WD4835-0	488 (B)/635 (R) nm single-mode tapered wavelength division multiplexer (FC/APC)	488(B)/635(R)nm	±5nm	≥18.00dB	≥50.00dB	Add Inquiry
WD4835-1	488 (B)/635 (R) nm single-mode tapered wavelength division multiplexer (FC/PC)	488(B)/635(R)nm	±5nm	≥18.00dB	≥50.00dB	Add Inquiry
WD4835-4	488 (B)/635 (R) nm single-mode tapered wavelength division multiplexer (bare fiber)	488(B)/635(R)nm	±5nm	≥18.00dB	≥50.00dB	Add Inquiry
WD4832-0	488 (B)/532 (G) nm single-mode tapered wavelength division multiplexer (FC/APC)	488(B)/532(G)nm	±5nm	≥16.00dB	≥50.00dB	Add Inquiry
WD4832-1	488 (B)/532 (G) nm single-mode tapered wavelength division multiplexer (FC/PC)	488(B)/532(G)nm	±5nm	≥16.00dB	≥50.00dB	Add Inquiry
WD4832-4	488 (B)/532 (G) nm single-mode tapered wavelength division multiplexer (bare fiber)	488(B)/532(G)nm	±5nm	≥16.00dB	≥50.00dB	Add Inquiry

Fiber optic wavelength division multiplexer (commonly used frequency band)

Product PN#	product name	Working wavelength	Working bandwidth	Isolation	Return loss
WD9850-1	980nm/1550nm single-mode tapered wavelength division multiplexer (FC/APC)	980nm/1550nm	±20/±20nm	≥20.00dB	≥50.00dB	Add Inquiry
WD9850-1	980nm/1550nm single-mode tapered wavelength division multiplexer (FC/PC)	980nm/1550nm	±20/±20nm	≥20.00dB	≥50.00dB	Add Inquiry
WD9850-4	980nm/1550nm single-mode tapered wavelength division multiplexer (bare fiber)	980nm/1550nm	±20/±20nm	≥20.00dB	≥50.00dB	Add Inquiry
WD1350-0	1310nm/1550nm single-mode tapered wavelength division multiplexer (FC/APC)	1310nm/1550nm	±10nm	≥18.00dB	≥50.00dB	Add Inquiry
WD1350-1	1310nm/1550nm single-mode tapered wavelength division multiplexer (FC/PC)	1310nm/1550nm	±10nm	≥18.00dB	≥50.00dB	Add Inquiry
WD1350-4	1310nm/1550nm single-mode tapered wavelength division multiplexer (bare fiber)	1310nm/1550nm	±10nm	≥18.00dB	≥50.00dB	Add Inquiry
WD1450-0	1480nm/1550nm single-mode tapered wavelength division multiplexer (FC/APC)	1480nm/1550nm	±5nm	≥16.00dB	≥50.00dB	Add Inquiry
WD1450-1	1480nm/1550nm single-mode tapered wavelength division multiplexer (FC/PC)	1480nm/1550nm	±5nm	≥16.00dB	≥50.00dB	Add Inquiry
WD1450-4	1480nm/1550nm single-mode tapered wavelength division multiplexer (bare fiber)	1480nm/1550nm	±5nm	≥16.00dB	≥50.00dB	Add Inquiry

Fiber optic wavelength division multiplexer (special wavelength)

Product PN#	product name	Working wavelength	Working bandwidth	Isolation	Return loss
WD1470-0	1434nm/1470nm single-mode tapered wavelength division multiplexer (FC/APC)	1434nm/1470nm	±5nm/±2nm	215.00dB	≥50.00dB	Add Inquiry
WD1470-1	1434nm/1470nm single-mode tapered wavelength division multiplexer (FC/PC)	1434nm/1470nm	±5nm/±2nm	215.00dB	≥50.00dB	Add Inquiry
WD1470-4	1434nm/1470nm single-mode tapered wavelength division multiplexer (bare fiber)	1434nm/1470nm	±5nm/±2nm	215.00dB	≥50.00dB	Add Inquiry
WD9860-0	980nm/1060nm single-mode tapered wavelength division multiplexer (FC/APC)	980nm/1060nm	±5nm/±5nm	216.00dB	≥50.00dB	Add Inquiry
WD9860-1	980nm/1060nm single-mode tapered wavelength division multiplexer (FC/PC)	980nm/1060nm	±5nm/±5nm	216.00dB	≥50.00dB	Add Inquiry
WD9860-4	980nm/1060nm single-mode tapered wavelength division multiplexer (bare fiber)	980nm/1060nm	±5nm/±5nm	216.00dB	≥50.00dB	Add Inquiry
WD1083-0	1033nm/1083nm single-mode tapered wavelength division multiplexer (FC/APC)	1033nm/1083nm	±5nm/±2nm	218.00dB	≥50.00dB	Add Inquiry
WD1083-1	1033nm/1083nm single-mode tapered wavelength division multiplexer (FC/PC)	1033nm/1083nm	±5nm/±2nm	218.00dB	≥50.00dB	Add Inquiry
WD1083-4	1033nm/1083nm single-mode tapered wavelength division multiplexer (bare fiber)	1033nm/1083nm	±5nm/±2nm	218.00dB	≥50.00dB	Add Inquiry

Mini fiber optic wavelength division multiplexer

Product PN#	product name	Working wavelength	Working bandwidth	Isolation	Return loss
MWD9850-0N	980nm/1550nm Mini single-mode tapered wavelength division multiplexer (FC/APC, 250 μ m bare fiber)	980nm/1550nm	960-990nm/1526-1570nm	≥19.00dB	≥50.00dB	Add Inquiry
MWD9850-1N	980nm/1550nm Mini single-mode tapered wavelength division multiplexer (FC/PC, 250 μ m bare fiber)	980nm/1550nm	960-990nm/1526-1570nm	≥19.00dB	≥50.00dB	Add Inquiry
MWD9850-4N	980nm/1550nm Mini single-mode tapered wavelength division multiplexer (bare fiber, 250 μ m bare fiber)	980nm/1550nm	960-990nm/1526-1570nm	≥19.00dB	≥50.00dB	Add Inquiry
MWD9850-0L	980nm/1550nm Mini single-mode tapered wavelength division multiplexer (FC/APC, 900 μ m loose tube)	980nm/1550nm	960-990nm/1526-1570nm	≥19.00dB	≥50.00dB	Add Inquiry
MWD9850-1L	980nm/1550nm Mini single-mode tapered wavelength division multiplexer (FC/PC, 900 μ m loose tube)	980nm/1550nm	960-990nm/1526-1570nm	≥19.00dB	≥50.00dB	Add Inquiry
MWD9850-4L	980nm/1550nm Mini single-mode tapered wavelength division multiplexer (bare fiber, 900 μ m loose tube)	980nm/1550nm	960-990nm/1526-1570nm	≥19.00dB	≥50.00dB	Add Inquiry
