9.06um low power bench top DFB-QCL mid-infrared quantum cascade laser 20mW (benchtop light source)

QCL9060-9.06um Low Power Benchtop DFB-QCL Mid-Infrared Quantum Cascade Laser is an industry-leading ultra-low power QCL-DFB laser developed by Idealphotonics in the first half of 2018. With a tunable range of over 100nm and an output power greater than 20mW, it meets the industrial demands of customers in gas sensing and other applications. Our laser features collimated output with stable power, high temperature and wavelength stability, which is significantly superior to traditional high-power quantum cascade lasers in terms of stability. It provides an excellent test light source for our mid-infrared testing customers.

Product features：Low power, high power、 Narrow linewidth、 Compact structure、 Software intelligent control、 Built-in FPGA

Application area：TDLAS NH3 high-precision trace analysis、 Mid-infrared test light source、 Mid-infrared device analysis

Unit Price

Please contact customer service for a discounted quote.

Part Number

LDC-MIR-QCL-W9060-1-DFB-020

Lead Time

Please contact customer service for lead time.

Stock

Please contact customer service for stock availability.

Add to Inquiry

Inquire online

General Parameters

Download Document

Dimensional Drawing

Parameters

Parameter	Unit	Specs
		Min.	Typ.	Max.
PN#		QCL9060
Output power	mW	20	-	40
Peak operating wavelength	um	9.0	9.06	9.16
Spectral width (FWHM)	MHZ	-	3	-
Side-mode suppression ratio (SMSR)	dB	20	-	-
Output isolation	dB	-	30	-
Wavelength temperature coefficient	nm/℃		0.6
Wavelength current coefficient	nm/mA		0.2
Output power stability (15 minutes)	%	-	±0.5	±1.0
Output power stability (8 hours)	%	-	±1.0	±2.0
Output power adjustable range	%	0	-	100
Output power adjustment mode		Software control
TEC stability	℃	-	±0.1	±0.2
TEC working range	℃	0	30	50
Operating voltage	VAC	100	220	240
Power consumption	W	-	-	2
Operating temperature	℃	0	-	55
Storage temperature	℃	-20	-	65
Dimensions	mm	340(L)×240(W)×100(H)mm
