In-line Polarization Controller, 1310nm SMF-28e fiber

Low insertion loss, high return loss, high operating power, epoxy-free optical path. Product applications: PM testing systems, laboratory testing.

Product features：Low insertion loss 、 High return loss 、 High operating power 、 Epoxy-free optical path 、 PM testing systems 、 Laboratory testing

Application area：Display panel testing 、 LED lighting flicker analysis 、 Toy light flicker frequency and power measurement 、 Gas analysis

Unit Price

Please contact customer service for a discounted quote.

Part Number

ILDP-31-B-2-2-2-10-1-1

Lead Time

Please contact customer service for lead time.

Stock

Please contact customer service for stock availability.

Add to Inquiry

Inquire online

General Parameters

Dimensional Drawing

Main Parameters

Parameters	Index
Operating Wavelength	1310 or 1550
Bandwidth	±20nm
Insertion loss	≤1.0dB
Degree of Polarization (DOP)	≤ 10%
Return loss	≥50dB
Fiber type	Input: Polarization-maintaining fiber
Fiber type	Output: Single-mode fiber
Optical power	≤ 500mW
Polarization direction	Polarized light emitted to the slow axis of the input PM fiber
Operating temperature	-5 to +70°C
Operating temperature	-40 to +85°C
Package size	B= Ø 5.5 x L56

Note:

High-power handling products can be provided upon request.

For devices with connectors, insertion loss will increase by 0.3 dB, and return loss will decrease by 5 dB.

Port Configuration

Model Example
