400-1100nm Silicon Photoelectric Balanced Detector 100MHz

The high-speed low-noise photoelectric balanced detection module integrates two matched ultra-low noise analog PIN detectors, a low-noise broadband transimpedance amplifier and an ultra-low noise power supply. It has the characteristics of high gain, high sensitivity, high bandwidth, low noise, high common mode rejection ratio, etc. It can effectively reduce the common mode noise of the signal and improve the signal-to-noise ratio of the system.

Product features：Low noise、 High gain、 High bandwidth、 Compact structure、 Built-in low noise isolated power supply

Application area：Distributed fiber optic sensing、 Lidar wind radar、 Optical coherence tomography、 Spectral measurement、 Ns-level optical pulse detection

Unit Price

Please contact customer service for a discounted quote.

Part Number

BPD-Si-100M-B

Lead Time

Please contact customer service for lead time.

Stock

Please contact customer service for stock availability.

Add to Inquiry

Inquire online

General Parameters

Download Document

Dimensional Drawing

Parameter:

Product model	BPD-Si-100M-B	BPD-Si-200M-B	BPD-Si-350M-B	BPD-Si-500M-B	BPD-Si-1G-B	单位
Detector model	Si
Wavelength	400~1100	400~1100	400~1100	400~1100	400~1100	nm
Bandwidth	100M	200M	350M	500M	1G	Hz
Detector responsivity	0.55@850nm	0.55@850nm	0.55@850nm	0.55@850nm	0.55@850nm	A/W
Transimpedance gain	30K	30K	30K	30K	30K	V/A
Saturated input optical power	250	250	250	250	250	μW
NEP	12	12	12	13	13	pW/Sqrt(Hz)
Common mode rejection ratio	>25	>25	>25	>25	>25	dB
Output impedance	50	50	50	50	50	Ω
Output coupling mode	DC/AC	DC/AC	DC/AC	AC	AC
Supply voltage	5	5	5	12	12	V
Supply current	0.5(max)	0.5(max)	0.5(max)	0.5(max)	0.5(max)	A
Optical input	FC/APC (Free space optional)	FC/APC (Free space optional)	FC/APC (Free space optional)	FC/APC (Free space optional)	FC/APC (Free space optional)
RF output	SMA	SMA	SMA	SMA	SMA
Dimensions	624725	624725	624725	624725	624725	mm
