400-1600nm单模光纤准直器

1064nm single-mode fiber collimator

Unit Price

Please contact customer service for a discounted quote.

Part Number

FCS64AFAY100

Lead Time

Please contact customer service for lead time.

Stock

Please contact customer service for stock availability.

Add to Inquiry

Inquire online

Main parameter

Download Document

波长	带宽	工作距离	束腰光斑	发散角	封装	出射损耗	回波损耗	模场直径	光纤类型	接头
405nm	±20nm	100mm	0.27mm	2.1mrad	Φ3.4mm	≤2.5dB	≥55dB	3.0±0.5um	405HP	FC/PC FC/APC LC/PC or Customer specified
		300mm	0.70mm	0.78mrad
450nm	±20nm	100mm	0.26mm	2.3mrad	Φ3.4mm	≤2.0dB	≥55dB	3.5±0.5um	450HP
		300mm	0.68mm	0.87mrad
525nm	±20nm	100mm	0.31mm	2.3mrad	Φ3.4mm	≤1.5dB	≥55dB	3.6±0.5um	450HP
		300mm	0.8mm	0.87mrad
635nm	±20nm	100mm	0.39mm	2.6mrad	Φ3.4mm	≤0.7 dB	≥55dB	4.2±0.5um	630HP
		300mm	0.85mm	1.0mrad		≤0.8 dB
		1000mm	1.32mm	0.7mrad		≤1.0 dB
780nm	±20nm	100mm	0.39mm	2.6mrad	Φ3.4mm	≤0.6 dB	≥55dB	4.5±0.5um	780HP
		300mm	0.99mm	1.0mrad		≤0.7 dB
		1000mm	1.55mm	0.7mrad	Φ4.0mm	≤0.9 dB
850nm	±20nm	100mm	0.37mm	3.0mrad	Φ3.4mm	≤0.6 dB	≥55dB	5.0±0.5um	780HP
		300mm	0.97mm	1.1mrad		≤0.7 dB
		1000mm	1.51mm	0.75mrad	Φ4.0mm	≤0.9 dB
980nm	±20nm	100mm	0.36mm	3.5mrad	Φ3.4mm	≤0.5 dB	≥55dB	5.9±0.3um	980HP
		300mm	0.96mm	1.4mrad		≤0.6 dB
		1000mm	1.48mm	0.87mrad	Φ4.0mm	≤0.9 dB
1064nm	±20nm	100mm	0.37mm	3.3mrad	Φ3.4mm	≤0.5 dB	≥55dB	6.2±0.3um	980HP/Hi1060
		300mm	0.99mm	1.4mrad		≤0.6 dB
		1000mm	1.53mm	0.87mrad	Φ4.0mm	≤0.9 dB
1310nm	±20nm	100mm	0.38mm	4.4mrad	Φ3.4mm	≤0.4 dB	≥55dB	9.6±0.4um	Smf-28e/ G657A1/ G657A2 ZBL
		300mm	0.73mm	2.3mrad		≤0.5 dB
		1000mm	0.91mm	1.9mrad	Φ4.0mm	≤0.7 dB
1550nm	±20nm	100mm	0.46mm	4.5mrad	Φ3.4mm	≤0.4 dB	≥55dB	10.4±0.5um	Smf-28e/ G657A1/ G657A2 ZBL
		300mm	0.85mm	2.4mrad		≤0.5 dB
		1000mm	1.35mm	1.7mrad	Φ4.0mm	≤0.7 dB
1650nm	±5nm	100mm	0.47mm	4.5mrad	Φ3.4mm	≤0.4 dB	≥55dB	10.9±0.5um	Smf-28e/ G657A1/ G657A2 ZBL
		300mm	0.89mm	2.4mrad		≤0.5 dB
		1000mm	1.22mm	1.7mrad	Φ4.0mm	≤0.7 dB
